AirCurve 10 CS PaceWave ASV with Humidifier
€ 4,500.00 SKU: 37283
The AirCurve™ 10 CS PaceWave is an adaptive servo-ventilator device providing unparalleled personalized therapy for central breathing disorders, such as central sleep apnea (CSA), Cheyne-Stokes respiration (CSR) and related obstructive events. This BiPAP boasts the most clinically-studied and proven ASV algorithm, and is the only adaptive servo-ventilator that targets the patient’s own recent minute ventilation.
The heated humidifier is sold separately. Add it to your cart here.
4.8 out of 5 based on 182 reviews
You may also like…
Description
AirCurve 10 CS PaceWave ASV with Humidifier
The ASV algorithm continuously tracks and learns from the patient’s respiratory rate to provide customized pressure that corresponds to the user’s exact breathing pattern, covering their changing needs on the fly.
Features
- Clinically-published AirCurve CS PaceWave ASV Mode;
- ASV Auto Mode;
- Pressure adjustment to correspond to the patient’s changing needs;
- Mandatory breaths delivery mode.
Other features
- Easy-Breathe pressure waveform that imitates the wave shape of normal breathing and replicates it for your breathing comfort;
- Continuous leak management for reliable therapy pressure delivery while maintaining patient-device synchrony;
- Climate Control with HumidAir humidifier (sold separately) and ClimateLineAir™ heated air tube. Delivers a constant, comfortable temperature and humidity levels during therapy. Minimize the common side effects of therapy to increase compliance.
ASVAuto mode
ASVAuto mode adapts to your ventilatory and upper airway stability needs on a breath-by-breath basis. By treating breathing disorders with auto-adjusting pressure support and upper airway obstruction with auto-adjusting expiratory positive airway pressure (EPAP), ASVAuto mode rapidly stabilises your respiration.
ASVAuto mode
ASVAuto mode adapts to your ventilatory and upper airway stability needs on a breath-by-breath basis. By treating breathing disorders with auto-adjusting pressure support and upper airway obstruction with auto-adjusting expiratory positive airway pressure (EPAP), ASVAuto mode rapidly stabilises your respiration.
The ResMed AirCurve 10 CS PaceWave ASV Package Includes:
- ResMed AirCurve CS PaceWave ASV;
- HumidAir Integrated Humidifier;
- Water Tub;
- Stylish Travel Bag;
- SD Card;
- Power Supply Unit;
- Air Tubing system.
Technical specifications
| CPAP | Yes |
| VAuto | No |
| S | No |
| T | No |
| ST | No |
| ASV | Yes |
| ASVAuto | Yes |
| Easy-Breathe waveform | Yes |
| SmartStart | Yes |
| MaskFit | Yes |
| Climate Control | Yes |
| Enhanced Climate Control Auto | Yes |
| Vsync leak management | Yes |
| Built-in wireless connectivity | Yes |
| myAir™ | Yes |
| Power Supply Unit | 90W |
| Typical Power Consumption | 53 W |
| Operating temperature range | +41F to 95F |
| Operating Humidity Levels | 10 to 95% relative humidity (non-condensing) |
| Operating altitudes | sea level to 2,591m |
| Pressure level | SlimLine: 26.6 dBA with uncertainty of 2 dBA – Standard: 26.6 dBA with uncertainty of 2 dBA Power level: – SlimLine: 34.6 dBA with uncertainty of 2 dBA – Standard: 34.6 dBA |
| Dimensions (H x W x D) | 4.57″ x 10.04″ x 5.91″ (116 mm x 255 mm x 150 mm) |
| Weight (device and standard water tub) | 44 oz (1248 g) |
| Weight (device and cleanable water tub) | 44 oz (1248 g) |
| Housing construction | Flame retardant engineering thermoplastic |
| Water capacity | To maximum fill line 380 mL Standard water tub – material: Injection molded plastic, stainless steel + silicone seal |
| Cleanable water tub – material | Injection molded plastic, stainless steel + silicone seal |
